Additional Cubit Footage with Lowered Rear Deck
Designed around a focus group of operators, Parcelport was created from the feedback of the Parcel Delivery Industry. Operators shared their experiences about products they used on a daily basis, what worked for them and what didn’t. We listened, took notes and brought the Parcelport to market. Parcelport incorporates many standard features such as Rocktop fiberglass wind fairing, rubberized flooring to keep cargo clean, dry and provide increased foot traction, translucent roof for increased interior light, an exclusive 29” aluminum rear drop floor for a lower ease of entry. Available side and rear door options and various shelving packages help make Parcelport the perfect fit for you.
| BODY SIZE | 12' SRW | 14' SRW | 14' DRW | 16' DRW |
|---|---|---|---|---|
| Interior Height | 6' 6" | 6' 6" | 6' 6" | 6' 6" |
| (A) Wheel Base | 138" | 158" | 158" | 176" |
| (B) Body Height | 111" | 111" | 111" | 111" |
| (C) Truck Length | 21' 6" | 23' 6" | 23' 6" | 25' 6" |
| (D) Overall Body Length | 13' | 15' | 15' | 17' |
| (E) True Body Length | 12' | 14' | 14' | 16' |
| (F) Body Width | 80" | 80" | 96" | 96" |
| (G) Load Width | 78" | 78" | 94.25" | 94.25" |
| (H) Door Opening Width | 50" | 50" | 50" | 50" |
| (I) Door Opening Height | 81.5" | 81.5" | 81.5" | 81.5" |
| (J) Ground to Bumper | 18.5" | 18.5" | 18.5" | 18.5" |
| (K) Ground to Floor | 21.5" | 21.5" | 21.5" | 21.5" |
| (L) Main Floor | 10' | 12' | 12' | 14' |
| (M) Drop Floor | 2' 2" | 2' 2" | 2' 2" | 2' 2" |
